Description
Kellys Bike Cliff 10 Red S
K20178
https://www.kellysbike.com/en/cross-c719/cliff-10-red-p64169
SPECIFICATIONS
- FRAME
KELLYS Crosslite - FRAME SIZE S / M / L
- FORK SR SUNTOUR M3010, 50mm, coil spring
- HEAD PARTS semi-integrated
- B.B.PARTS cartridge (124.5mm)
- CRANKSET PROWHEEL (48x38x28T) – length 170mm
- SHIFTERS SHIMANO ST-EF41-7 EZ-fire Plus
- F/DERAILLEUR
SHIMANO TY710 (31.8mm) - R/DERAILLEUR SHIMANO TY300 (direct mount)
- SPEED 21
- CASSETTE SPROCKET SHIMANO CS-HG200-7 (12-32T)
- CHAIN KMC Z7 (114 links)
- BRAKES APSE V-brake
- BRAKE LEVERS SHIMANO ST-EF41-7 EZ-fire Plus
- HUBS alloy / SHIMANO TY500 (32 holes)
- RIMS KLS Draft 622×21 (32 holes/eyelets)
- SPOKES steel
- TIRES INNOVA 44-622 (700x42C)
- STEM KALLOY Uno – diam 28.6 mm/bar bore 25.4mm / 15° / length 75mm (S), 90mm (ML)
- HANDLEBAR steel RiseBar – diam 25.4mm / rise 30 mm/width 640mm (S – M), 660mm (L)
- GRIPS KLS Token Density
- SEAT POST steel – diam 27.2 mm/length 330mm
- SADDLE KLS CrossLine
- PEDALS plastic
KELLYS Crosslite
S / M / L
SR SUNTOUR M3010, 50mm, coil spring
semi-integrated
cartridge (124.5mm)
PROWHEEL (48x38x28T) – length 170mm
SHIMANO ST-EF41-7 EZ-fire Plus
SHIMANO TY710 (31.8mm)
SHIMANO TY300 (direct mount)
21
SHIMANO CS-HG200-7 (12-32T)
KMC Z7 (114 links)
APSE V-brake
SHIMANO ST-EF41-7 EZ-fire Plus
alloy / SHIMANO TY500 (32 holes)
KLS Draft 622×21 (32 holes/eyelets)
steel
INNOVA 44-622 (700x42C)
KALLOY Uno – diam 28.6 mm/bar bore 25.4mm / 15° / length 75mm (S), 90mm (ML)
steel RiseBar – diam 25.4mm / rise 30 mm/width 640mm (S – M), 660mm (L)
KLS Token Density
steel – diam 27.2 mm/length 330mm
KLS CrossLine
plastic
